Forklift

SCHORR RR12HHEF 2,5m / 3m / 3,5m mit FREIHUB

SCHORR electric pallet truck with free lift 1200kg load capacity
Gsdpemv Ek Ijfx Ag Hsuk

-- The following lifting heights are available (2500mm / 3000mm / 3500mm)
-- Ideal for low ceiling heights
-- Mast only extends from the height of the mast (FREELIFT)
-- Fully electric & self-propelled with various driving modes
-- Incl. 24V 100Ah gel batteries (maintenance-free) and integrated charger
-- High-quality CURTIS control unit (waterproof)
-- Polyurethane tires: durable and abrasion-resistant
-- Various riding programs (incl. "Turtle" / "Slow mode")
-- Safe stand thanks to electromagnetic brakes
-- High-performance hydraulic pump

With its free lift, the high-lift truck is particularly suitable for warehouses and rooms with low ceilings. The mast only extends from the height of the mast and thus enables safe and effective working in confined spaces.

Depending on the version selected, it can reach a lifting height of 2500 mm to 3500 mm.

Prices depend on lifting height / variant:

2500mm lifting height: 3199€
3000mm lifting height: 3219€
3500mm lifting height: 3239€

The forks have a standard Euro pallet dimension (fork length of 1150mm).

The two built-in 12V gel batteries with a capacity of 100Ah ensure a long running time of up to approx. 4 hours. Charging the pallet truck is easy: simply plug it into a conventional 230V socket and the pallet truck is ready for use again in no time.

The pallet truck has a high-quality CURTIS control unit, which is waterproof and can therefore also be used in damp or cool rooms for short periods.

The high lift pallet truck can be operated intuitively using the built-in tiller. The control instruments such as the battery charge indicator, the emergency switch and the keys are centrally located and therefore in the operator's direct field of vision.

In addition to the normal transport speed of approx. 4.2 km/h, it also has a "creep mode". Creep mode enables slow and precise movement, allowing the operator to maneuver even in the narrowest aisles and shelves.

Technical data:

Load capacity: 1200kg
With free lift
Lifting height: 2.5m / 3m / 3.5m (depending on selected version)
Motor power: 750W
Weight: 465kg

Lifting speed:
-- with load: 83mm/s
-- without load: 136mm/s

Lowering speed:
-- with load: 112mm/s
-- without load: 98mm/s.

Climbing ability:
-- with load 6%
-- without load 8%

Turning radius: 1366 mm
