BOXMAT HD – Automatic Box Making Machine

Zemat Boxmaker HD

HIGH PERFORMANCE - BUILT FOR PROCESSING SINGLE, DOUBLE, AND HEAVY-DUTY BOARD!
Main features:
Gisdowrrfcopfx Ab Ter
- 40+ pre-installed FEFCO styles, 100+ available box shapes
- One-pass operation for seamless box production
- Supports single, double-wall, and high-strength board
- Works with sheets and concertina board
- Integrated die-cutting system
- Fast tool changeover - less than 20 seconds
- Fully automatic servo drive setup
- Large 19" touchscreen HMI with intuitive software
- Slotting, creasing, cutting, gluing, and printing in a single operation
- Detachable feeder (compatible with manual or vacuum feeding)
- Remote diagnostics and updates via integrated VPN connection
_____
Optional functions and upgrades:
- Gluing system - synchronized cold glue application device
- miniFLEXO - compact single-color flexo printer
- Flexomat - full-format flexo printer
- Vacuum feed system - compensates for sheet curvature
- 3D scanner - automatic product scanning and data entry
- Automatic box folding system
- Fully automatic production line
_____
Technical data:
- Power supply: 3 x 380/415/480 V
- Installed power: 8.5 kW
- Production efficiency: Up to 500 boxes per hour
- Maximum box size: 2400 mm (94") width x 9999 mm (394") length
- Minimum box size: 250 mm (10") width x 750 mm (30")
- Slot width: ~7-8 mm (~5/16")
- Machine footprint (L x W x H): ~3600 x 1900 x 1750 mm
- Machine weight: ~3800 kg (7900 lbs)

For further information, contact us, we are happy to help you
