Injection molding machine

Battenfeld HM 3500 /1900

Battenfeld HM 3500 /1900 Injection Moulding Machine
Year: 2005

Clamping Unit:
Clamping force: 3,500 kN
Hnjdsw Dcxdjpfx Adiog
Platen dimensions (H x V): 1,100 mm x 1,060 mm
Tie bar distance (H x V): 800 mm x 710 mm
Mould opening stroke: 670 mm
Minimum mould height: 375 mm
Maximum mould height: 710 mm
Daylight: 1,380 mm
Ejector stroke: 250 mm
Ejector force: 81 kN
Injection Unit:
Screw diameter: 55 mm
L/D: 22
Injection pressure: 2,481 bar
Screw stroke: 325 mm
Shot volume: 772 cm³
Injection weight (PS): 710 g
Injection speed: cm³/s
Screw speed: 294 rpm
Max. plasticising rate: 68 g/s
Number of heating zones: 1 + 5

Electrical & Hydraulic Equipment:
Installed heating power: 45 kW
Pump capacity: 26.6 kW
Tank volume: 660 l
Machine Dimensions & Weight:
Approx. dimensions: 7.53 m x 1.79 m x 2.31 m
Total machine weight: 15,200 kg
