CM S 60 Cutting Mill

Crushmaster S 60

APPLICATIONS
The S-Series granulators are mainly used as large central granulators for
Ljdpfxep N D N Se Adhsah
In-house recycling applications for processing large thick-walled parts in one
stage or as a second-stage granulator after a shredder to achieve higher results or throughput rates

GENERAL DESCRIPTION
The high-performance S-Series granulators offer widths from
600 to 1000 mm with diameters of 400 and 560 mm.
The all-welded heavy steel construction is designed to withstand
the most demanding and universal applications. Rotor bearings, blades
brackets and rotor shaft are oversized. The standard V-cut ensures a high
quality grind with a very low percentage of fines in the starting material.
The removable third stator blade (optional) acts as a deflection wedge
and allows the machine to be quickly adapted to different application
scenarios. Other standard equipment also includes easily adjustable blades
from the outside, reducing the risk of contamination.

S-SERIES - HIGH PERFORMANCE GRANULATORS ADVANTAGES:
"The easily removable deflector wedge acts as a third stator blade and can
be used to adjust the aggressiveness of the rotor at the first cut point.
The V-Cut technology produces a high quality regrind, with simultaneous
reducing energy consumption and noise.
The high performance bearings are separated from the cutting chamber to prevent lubricant ingress and bearing failure to prevent material contamination.
"Both rotor and stator knives are externally adjusted.

Rotor diameter (mm) 400
Rotor width (mm) 600
Drive capacity (HP) 50
Rotor knives (pieces) 5 x 2
stator knives (rows) 2 + 1
Hopper opening (mm) 630 x 600
Total length (mm) 1950
Length machine (mm) 1876
Width total (mm) 1359
Width machine (mm) 1000
Height (mm) 3040
