LAS 28 CO2 Laser

Systemtechnik Hölzer GmbH LAS 28 XL - CO2-Laser 30Watt

With the powerful laser software, texts, numbers, 2D codes, QR codes and logos can be realised with just a few clicks and without extensive programming knowledge. The software automatically counts up serial and article numbers once they have been set. In addition, the software can read data (variable information such as drawing numbers, project designations, etc.) from existing tables and automatically transfer it to predefined areas. The use of a hand scanner is also possible.

The standard equipment includes a laptop incl. holder with Windows operating system. The LAS 28 laser model can optionally be equipped with a rotary axis (3-jaw chuck) for labelling cylindrical parts. Other options, such as lateral cantilevers for labelling long parts, can also be realised.

30W CO2 laser (optional: 60 W)

- Wavelength 10640nm
- marking field size 220x220 mm
Gedpfowkpyhsx Ab Tobk
- optional: rotary axis (3-jaw chuck)
- optional: exhaust system (incl. activated carbon filter)
- optional: extension arm for large workpieces (also on both sides)
- marking software EZCAD in German / English
- Pilot laser (simple preview)
- focus finder (easy focus adjustment)
- max. part height approx. 300mm
- electrically adjustable Z-axis
- Laptop incl. holder with operating system Windows
- frame made of aluminum profile
- air cooled
- door width approx. 720mm / door height: 400mm
- Connection 230V
- Dimensions: approx. 1000 x 800 x 2000 mm (LxWxH)
- Weight: approx. 140 Kg
