🟦 Semi-automatic Powder Coating Plant – Compact Container System

Modern semi-automatic powder coating line built in a container-type enclosure, consisting of a powder coating booth, curing oven, and automatic transport system.
This unit is a compact and mobile solution designed for coating small metal parts — ready for operation anywhere after connecting to power supply.
Ideal for production companies, workshops, or service providers looking for an efficient and flexible coating system.

🔹 Technical Specifications

CURING OVEN
- Working chamber dimensions: 4000 x 700 x 1300 mm (L x W x H)
- Heating power: 24 kW
- Motor: 2.5 kW, 1500 rpm
- Radial fan capacity: 4500 m³/h
- Thermal insulation: 150 mm
- Maximum temperature: 250°C

POWDER COATING BOOTH
Bodpfxexlr Emj Ai Dslk

- Working chamber dimensions: 2000 x 600 x 1400 mm (L x W x H)
- Filtration unit:
* Motor: 2.2 kW, radial fan 12,500 m³/h
* Two conical polyester filters L600
* Twist-type filter mounts
* Pneumatic powder cleaning system with adjustable cyclic discharge

AUTOMATIC TRANSPORT SYSTEM
- Travel length: 11,500 mm
- Hanger spacing: 250 mm
- Number of hangers: 45 pcs
- Maximum speed: 4 m/min
- Motor power: 0.75 kW

🔸 Features and Advantages
* Compact container design – easy to transport and quick to install
* Low energy consumption and small footprint
* Continuous process ensured by automatic conveyor system
* High-efficiency filtration system
* Fully equipped “plug & play” unit – ready to start immediately
