Roller conveyor turnout sorter switch diverter...

Gebhardt Gebhardt 45° 1900-1800-550

Gebhardt roller conveyor turnout sorter switch diverter ejector 45° 1900-1800-550
RA1149
TYear of manufacture 2007

perm. weight load: 30 kg/m
dead weight: 40 kg/m
roll width: 550 mm
nominal/external width (NB): 610 / 1800 mm
conveying length: 1900mm
push-off element: roller
adjusted headroom: 680 mm
conveying speed: 0,35 m/sec.
brake for dust operation on discharge track
drive of discharge mechanism: electric
dimensions of the conveyed material: l x w = 600 mm x 400 mm

Optional:
Adjusted height on your request
Electrical attachments like light barriers, barcode sensors
Gedpjk Aa Eiefx Ahpobr
Control/Software


Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany

For individual, professional advice, simply contact us.
Simply contact us by phone or e-mail.
We will be happy to help you with the planning and implementation of your projects.
We look forward to hearing from you.
With kind regards
Your team at Dr. Sonntag GmbH & Co. KG
Your specialist and contact for intralogistics
