Spraying machine KaMA KR BM 1000, with Pump and S

Kama KR BM 1000 B

Spraying machine KaMa, KR BM 1000 B,

The spraying machine is a demonstration model from a trade fair. It was only used for test and demonstration purposes.

With 1 piece HD pump Bings Marple 8/25 up to 175bar and 4 pieces
airless spray guns Krautzberger KAA1300.
Machine equipped with change-over valve for quick color change,
lever switchable to max. 3 color circles and 1 rinsing agent pump (options).
In Ex-version.
Machine is ready for demonstration at the warehouse in Blomberg.

- Producer Ka-Ma
- Type KR BM 1000 B
Csdpfx Ageumvnhs Topt
- Year of construction 2023
- Working width 1.200 mm
- Single gun drive system
- Dry filter system
- Transport belttransport System
- Feed speed adjustable 2 - 8 m/min
- Lacquer reclaiming system with v-belt
- Gun control system SPS, LS
- Number of installed lacquer circles 3 Stk.
- Number of installed spraying guns 4 Stk.
- quick change system for spraying guns
- spray gun type Krautzberger KAA1300, Airless
- Airless spraying system
- Height adjustment for spraying guns 150 mm
- Producer lacquer pump Binks Maple 8/25 bis max. 175bar
- Supply air box
- Suitably for water based lacquer
- Length 3243 mm
- Width 3482 mm
- Height 2450 mm
- Voltage / HZ 400 / 50
- Colour 7035, lichtgrau
- Weight 3.100 kg
_____

Optionally, we can also provide you with a quotation for the assembly and start-up of the system, as well as training for your employees.
We also offer regular maintenance and servicing of the machine on request.
For further information, get in touch with us!
