Wood shredder

muetek MGZ 630

The ideal machine for shredding hardwood and softwood
Another machine, available immediately (ex works Neckartailfingen)
.
Motor: 18.5 kW; 400 V - 50 Hz - 3 ph,
Knives: 14+2 pieces, 40x40mm, multiple rotatable,
Rotor diameter: 260 mm,
Control: Omron SPS,
Cutting unit opening 600 x 800 mm,
hopper volume approx. 0.6 qbm,
hydraulically operated pusher
Screen perforation of your choice (12 - 40 mm)
Suction nozzle Ø 160 mm
Weight approx. 1,300 kg
Dimensions (lxwxh) approx. 1737 x 1167 x 1650 mm
Kedped E R D Sjfx Adioll
.
The following options are available at extra cost:
- Additional row of knives + 995 € net (28 instead of 14)
- Surcharge for 4-sided segment shelf + € 2,170 net
(prevents blocking of the pusher. Recommended for materials with a thickness of less than 3 mm)

- Raise shredder by 30 cm (preparation for conveyor belt) + € 1,980 net
- Angled conveyor belt (discharge height approx. 220 cm) + €8,770 net
- Overbelt magnet + € 5,980 net
- Conveyor belt and overbelt magnet control + € 2,750 net
(start and stop synchronized with the chipper)
- Special bearing +1,540 € (rarely required. Closed, even more stable rotor bearing. Possibly a consideration for sieves smaller than 15 mm or with a lot of fines. Not necessary if the bearings are lubricated with grease every approx. 2 weeks during operation)
.
Requirements for the raw material:
- The moisture content (atro) must be below 30 %
- Metals and mineral impurities such as sand, stones etc. lead to increased wear.
.
We will be happy to carry out a free test with your material and invite you to visit us in Neckartailfingen. It is also possible for you to send us your material by freight forwarder and we will document the test with pictures and videos.
