Cell analyzer Cell culture analyzer

Roche Cedex HiRes

Cell culture analyzer for cell counting

The Cedex® HiRes Analyzer is a fully automated, image-based cell analyzer,
that provides information on cell concentration, viability, aggregates and
morphological parameters such as cell diameter and cell density.
The analyzer uses the proven Trypan blue exclusion method
for cell counting and a high-resolution image scanner to analyze cells and objects.



Technical specifications

Measuring method:
High-resolution scanner technology
Digital image recognition
Complete flow chamber inspection for full transparency of cell culture analysis

Detectable measuring range
Objects 1 - 70 μm
Cell diameter 2 - 40 μm

Detectable cell density range: 5 x 104 - 1 x 107 cells/mL

Required sample volume: 300 µl

Sample input:
Integrated high-speed multi-sampler for single samples and multiple runs

Maintenance: Automated cleaning and maintenance procedure

Software features:
Diameter histogram with cell size distribution
Bwedjwgix Aopfx Agmei
Aggregate histogram
Compactness histogram to visualize cell morphology
Easy creation of user roles for multiple or single users

Live operator:
High-speed real-time parameter optimization for specific cell lines
User-defined analysis of acquired images

Database filter diagram:
Saves all results and images
Measurement results easily retrievable via searchable directory

Operating conditions:
Temperature: +10 to +40°C (optimum +20 to +30°C)
Humidity: 20-80% relative humidity (without condensation)

Electrical requirements:
Power requirements: 100-250 V AC
Power consumption: 60W
Frequency: 50 Hz - 60 Hz

Physical dimensions:
Width: 405 mm
Depth: 535 mm
Height: 465 mm
Weight: 26.9 kg

Certification: Audit trail for compliance with 21 CFR part 11
