X-ray Inspection System

AMTEC XRI 200CC PRO

X-ray inspection system especially for tin cans and plastic containers, jars. Suitable for detecting foreign objects made of metal, glass, stone, plastic, etc. in food or non-food items. - Specifications: conveyor belt width: 200 mm; detection accuracy: Pb from Ø 0.2 mm, Fe from Ø 0.28 mm, SUS from Ø 0.28 mm, non-metallic such as stone, glass, from Ø 1.2 mm; X-ray output: 150 kVp, 7.5 mA; X-ray detector resolution: 0.4 mm; X-ray emissions: < 1usv/h; X-ray beam: vertical scan; conveyor belt height: 900 ± 30 mm; conveyor speed (dependent on product dimensions): 10 –60 m/min; screen: 15" touch screen; software: intellisens®X-ray; operating temperature: 5 – 35 °C; reject system: optionally available according to requirements; power: 220VAC, 50/60Hz; dimensions of the system: L2000xW1300xH2060 mm; weight: 650 kg.

Dcodpfov Nm I Ujx Akcsh
Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.
