Mini excavator

Kingway Minibagger YAMA H10 Joystick Koop Euro 5

(In our offer you will also find the larger YAMA H12 mini excavator with an operating weight of 1200 kg, equipped with a YANMAR engine with 3 cylinders and an oil cooler - price: € 10,504 net.
Also available is the YAMA H12 K model with a cabin, also with a YANMAR engine - 3 cylinders - price: € 12,000 net).

The YAMA H10 model is the ideal equipment for the most demanding construction, electrical, plumbing, renovation and service companies in similar industries. The YAMA H10 model is additionally equipped with a swivel arm, which makes working in tight spaces much easier. We also guarantee equipment service after the warranty period. Mini excavators are manufactured on the basis and under the supervision of European technicians. The equipment consists of a strong structure, it can work in all conditions.

BASIC PARAMETERS:

⦁ Model: TW10
⦁ Machine weight: 950 kg
⦁ Bucket capacity (3 buckets in set): 0.025 m3
⦁ Engine model: KOOP
⦁ Engine power: 11/2500 HP/rpm
⦁ Number of cylinders: 1
⦁ Oil cooler: NO
⦁ Swing arm: YES
⦁ Gradeability: 30o
⦁ Gear pump
⦁ Pressure: 16 MPa
⦁ Flow: 18 l/min
⦁ Maximum speed: 2 km/h
⦁ Platform speed: 10 rpm
⦁ Bucket breakout force: 9.4 kN
⦁ Arm impact force: 5.8 kN

DIMENSIONS:

⦁ Transport length: 2870 mm
⦁ Width: 930 mm
⦁ Height (with/without roof): mm 2285/2030 mm
⦁ Blade width: 937 mm
⦁ Blade height: 210 mm
⦁ Track spacing: 746 mm
⦁ Track width: 180 mm
⦁ Ground clearance: 405 mm
⦁ Standard bucket width: 380 mm

WORKING RANGE:

⦁ Digging height: 2500 mm
⦁ Discharge height: 1750 mm
⦁ Digging depth: 1730 mm
Bwsdpfxovz T H Is Af Djg
⦁ Maximum vertical digging depth: 1655 mm
⦁ Digging radius: 3030 mm
⦁ Minimum turning radius: 1490 mm
⦁ Digging radius on ground: 2940 mm
⦁ max height of raised blade: 170 mm
⦁ Blade lowered depth: 240 mm

PRICE:
€7,303 net
€8,690 gross

- INCLUDING 3 excavator buckets (300, 500, 800)
- For a machine that is regularly serviced by us, we EXTEND the WARRANTY to TWO YEARS
- FREE 12-month WARRANTY - after this period has expired, we offer all original parts if required!
- FREE delivery within a radius of 200 km
- Sales WITHOUT TAX possible (only with VAT number)- FINANCING possible
- We are always at your disposal!

KINGWAY GERMANY is the only stationary distributor of the Kingway brand in Germany. Only here can you view and try out all the machines on site.

We are the largest importer of construction and agricultural machinery in Europe and the head office of Kingway in Germany. We have a huge range of machines in stock, with around 70 machines available at any time. We deliver machines throughout Germany, Austria, Switzerland, Italy and other neighbouring countries and for our customers we also offer access to all spare parts. Book an appointment and come for a test drive!
