CNC Horizontal Machine centers SCM Record 110 AL TVN Prisma 2006

SCM Record 110 AL TVN Prisma

Empty weight: 4.000 kg
Price: On request

What are Presale Items at Second Owner?

Presale items are machines that we sell in their current condition ("as-is"). We have purchased these machines based solely on photos and sell them with the information provided in the advertisement. Unfortunately, we do not have additional details, such as exact dimensions or machine specifications. Additionally, these machines are often not yet in stock and have not been inspected by us.

These machines are offered at competitive prices, which means the prices are lower than usual, but the risk lies entirely with the buyer. Please carefully review the information in the advertisement before making a purchase.

If you have any questions, feel free to contact us!


- Year: 2006
- Documentation available: No
- CE marking present: Yes
- CE certificate present: No
- Number of milling spindles [pcs.]: 1


- └ Milling spindle 1:


- - Number of controlled axes [pcs.]: 5
- - Min. spindle speed [rpm]: 600
- - Max. spindle speed [rpm]: 20000
- - Main motor power [kW]: 11
- - C-axis present: Yes




- Type milling table: Beam table
- Tool clamping system: HSK-F63
- Drilling unit present: Yes


- └ Horizontal drill spindles [pcs.]: 6
- └ Vertical drilling spindles [pcs.]: 12


- Saw unit present: Yes
- Tool changer positions [pcs.]: 16
- System/software: Xilog plus
- Safety feature: Safety mat
- Vacuum pump present: Yes


- └ Main motor power [kW]: 5.5
- └ Capacity [m³/h]: 250


- CNC options: Offcut conveyor, Manual control
- Table length [mm]: 3050
- Table width [mm]: 1240
- Z-axis working range [mm]: 200
- X-axis maximum stroke [mm]: 3500
- Y-axis maximum stroke [mm]: 1815
- Z-axis maximum stroke [mm]: 440
- Transport weight [kg]: 4000kg
Fedpfx Agjx Hfiko Hopr
- Transport packages [pcs.]: 1

Financial information
VAT: The price shown is exclusive of VAT
VAT/margin: VAT deductible for entrepreneurs

Delivery and trade-in always possible for everything in the industrial sectors
