Insulation and sheathing system

NOKIA-MAILLEFER

Technical condition: Electrical system retrofitted in 2006.

Technical details:

Control system: Siemens S-5, line control: CP Line
Materials processed to date: PE, LLD, PP, PUR
Screw diameter: 1 x 80 / 1 x 45 mm
Screw length: 24 D
Minimum cable diameter: 2 mm
Maximum cable diameter: 22 mm
Maximum speed: 280 m/min
Injection head: included
Kledpfx Afjzf A Npe Aou
Injection head manufacturer: Erocab
Operating voltage: 3x400 V
Frequency: 50 Hz
Control voltage: 24/230 V
Electrical cabinet: included
Diameter measuring device: included
Plasticizer: included
Unwinder: included
Rewinder: included
Caterpillar, belt, and disc take-offs: included
Extruder: included
Number of extruders: 2
Cooling trough: included
Dancer/accumulator: included
Installation length: 70 m

Consisting of:

ITAL SPA/1250 unwinder
NOKIA-MAILLEFER JF 18 unwinder
NOKIA-MAILLEFER NMB 80-24D extruder
NOKIA-MAILLEFER NMC 45-24D co-extruder
NOKIA-MAILLEFER U4A caterpillar
ITAL VRR/3-600-63 cooling line
ITAL ACO 350 accumulator
ZUMBACH DSt.28A.30.KE40-RS spark tester
ZUMBACH ODAC 34XY diameter measuring device (hot)
Color mixer
CAPnet meter counter
MAILLEFER caterpillar
ZUMBACH ODAC 34XY-Jn-F diameter measuring device (cold)
ITAL ACV/350-4.5 dancer
Drum flange diameter max: 1200 mm
NOKIA-MAILLEFER Bobinoir JF22 rewinder
Drum flange diameter max: 2200 mm
MAILLEFER JB dancer
KBA-Metronic GmbH alphajet printer
KBA-Metronic GmbH alphajet printer
CAPnet CHA 20 40 caterpillar take-off for accumulator
