Band saw

Panhans BSB 600

New machine

Year of manufacture 2024

Equipment and technical data:

· Wheel diameter: 600 mm
· Belt speed: 1550 m/min
· Cutting height: 400 mm
· Cutting width: 580 mm
· Blade length max.: 4735 mm
· Saw blade width min. / max.: 15 mm / 30 mm
· Optional with special covering saw blade width min. / max.: 8 mm / 25 mm
· Table size: 810 x 590 mm
· Table height: 920 mm
· Extraction nozzle: 2 x Ø 100 mm
· Motor power: 2.2 kW / 3 HP
· Voltage: 400 V / 50 Hz
Gisdpfx Asw Nablsb Tjr
· Color: RAL 7035 light gray and RAL 5000 violet blue
· Net weight: approx. 275 kg
TECHNICAL DESCRIPTION
· Solid German mechanical engineering
· Machine stand in an attractive, modern, torsion-free double-chamber welded steel construction
· Upper and lower doors secured by limit switches
· Upper and lower precision band saw blade guide APA 2, size. 2
· Finely planed gray cast iron table
· Swiveling table top up to 45°
· Dynamically balanced band saw wheels with vulcanized rubber bandages
· Stop ruler can be used to the left of the saw blade, stop profile can be folded over
· Blade tension indicator
· 1 saw blade 4735 x 25 x 0.6 mm, tooth width 9 mm, No. 3780.250D
· Mechanical height adjustment of the saw blade guard using a handwheel with locking pinion
· From 2.2 kW - rotary cam switch with direct start and emergency stop button
· From 3.0 kW - rotary cam switch with star-delta start and emergency stop button
· Mechanical motor brake with main switch and motor protection relay
· CE-compliant

Incl. transport pallet
Incl. pre-freight to 65239 Hochheim

Availability: short term
Storage location: Flörsheim
