ASCO SD Mini 2025 – New Compact Mobile Drum Screen – Latest Model 2025

ASCO SD Mini - 2025

Applications & Customer Benefits:

The ASCO SD MINI Screen Drum is built for efficient material screening in recycling, construction, agriculture, and gardening. Its compact, foldable, and semi-mobile design ensures quick setup, transport, and high performance - even with moist or sticky materials. Perfect for small to mid-scale operations needing flexible and reliable screening.

Bjdpfx Asw R Txmeb Sowr
Key Features:
• Stepless, reversible drum rotation with quick drum change
• Adjustable screen angle and variable height for easy setup and transport
• Three drum variants with specific perforation options
• Integrated cleaning brush and vibration motor for smooth operation
• Robust, user-friendly design with single-wheel drive and hour counter

Tech Highlights:
Drum length 1.49 m · Usable drum length 1.25 m · Outer diameter Ø 0.8 m · Usable screening surface 3.15 m² · System capacity 5 - 40 t/h · Mesh size Ø 4 - Ø 100 mm · Hopper opening 1600 × 760 mm · Shovel width 1.5 m · Speed 5 - 20 rpm · Drive power 400 V / 2.2 kW · Filling height 1.5 - 1.86 m · Weight 600 kg
