Heavy duty shelf

Kragarmregal einseitig Höhe: 4.200 mm Nutztiefe: 1.200 mm / Länge: 4.000 mm

Cantilever rack in painted version (RAL 7016 anthracite):

Scope of delivery:
4 shelf uprights height 4,200 mm with base section 1,200 mm usable depth
12 cantilever arms with 1,200 mm usable depth
Longitudinal and diagonal braces for 1,300 mm upright center distance (4,000 mm shelf length)
Fastening material (screws, nuts and washers)

- (*Delivery or collection in approx. 1 - 2 weeks)
Cpodpfx Aemhhypog Tjt
- (*No damage to paintwork!)
- (*No damaged components!)
- (*Replacement parts can be reordered and extended at any time)
- (*Offer available in larger quantities: approx. 50 stands in stock)

Net price: € 1,990.00 plus VAT.

Detailed description:
- Sturdy steel construction made of IPE profiles (screw system)
- Surface painted in RAL 7016 (anthracite)
- Shelf height 4,200 mm
- Load capacity per upright 2,200 kg
- Foot section and cantilever arms with 1,200 mm usable depth
- Cantilever arms height-adjustable in 100 mm increments
- 3 screw-on cantilever arms per upright, standard (= 4 storage levels)
- Load capacity per cantilever arm 740 kg
- Including longitudinal and diagonal bracing for 1,300 mm spacing
- Shelf length = 4,000 mm
- Including fixing material (without floor anchors)
- With assembly instructions and load plates C4 according to DIN standard

- Expert advice by telephone
- Made in Germany
- Short delivery time
- On-site collection possible

Our cantilever racks are produced exclusively in Germany.
We offer reliable freight with notification prior to delivery.
The material is sensibly packed to enable easy unloading.
Delivery can be made in approx. 1 - 2 weeks after receipt of order.

For outdoor installation, the load-bearing capacity is reduced by the wind and snow load.
The surface must be concrete, level and suitable for dowels and must be able to bear the loads. The customer must check and ensure that the ground conditions and load-bearing capacity as well as any necessary official approvals are in place.

The shelf stands must be anchored to the floor on site; anchoring to the wall is not necessary and not recommended.
According to the employers' liability insurance association, it is recommended that the uprights on the uppermost storage level protrude at least 500 mm from the top edge of the uprights.
