Metal Gringing & Edge Rounding Machine

NS Maquinas DM 1100 C

Metal deburring and edge rounding machine – DM1100 C – performs edge rounding and removes sharp edges on both external and internal contours of stainless steel, steel or aluminium parts either cut in laser, shear or punching machine.

This machine works metal parts of different dimensions including products as small as 50x50mm.

DM1100 C – Metal Deburring Machine has a station with double cross belts for the metal deburring and edge rounding, leaving clean, soft and burr-free edges on the complete parts.

High performance on all edges and also on internal holes.

Two cross belts mounted with abrasive blocks run in opposite directions, completing edge rounding on the complete area of the part.

DM1100 C can edge round parts with plastic foil, keeping the original finishing and assuring the work purely on the edges.

Technical Specifications:
Cgsdpfxjd Evcwj Ap Aju

Working capacity (mm) 1100x50
No. Cross belt stations 2
Cross belt speed (m/s) 8
Feeding speed (m/m) 0.6-3.2
Cross Belt Motor (kW) 3
Feeding motor (kW) 0.18
Total power (kw) 6.2
Consumption (A) 13
Dust extraction connection per head (Ø mm) 100
Dimensions (mm) 2270x1560x1940
Weight (kg) 1200
