Cylindrical Grinding Machine

JONES & SHIPMAN Suprema Easy 1500 E

grinding diameter max. 320 mm
grinding length 1.500 mm
centre height 160 mm
Control Touch Jones & Shipman
between centers max. 100 kg
table:
Traverse Z-Axis 1.645 mm
traversing speed 0,0001 - 12 m/min
swivable +5 / -5 °
x-axis:
Traverse X-Axis 260 mm
traversing speed 0,0001 - 6 m/min
grinding head:
grinding wheel motor 7,5 kW
cutting speed 45 m/s
Grinding wheel Ø x width x bore 450 x 50 x 203,2 mm
Tailstock:
Swivel range -15 / +90 °
turning speed range 0 - 660 U/min
Torque 27 Nm
tool adaptor MK 3
total power requirement kW
weight of the machine ca. 8,5 t
dimensions of the machine ca. 5,5 x 2,5 x 2,0 m
Cylindrical Grinding Machine
JONES & SHIPMAN - Suprema Easy 1500 E

- Replacement grinding wheel flange
- Multi-grain diamond (for circumferential and lateral dressing, 10mm, 1 carat)
- Tailstock with micro adjustment (max. adjustment range +-0.05mm)
Gjdpfx Abjtqmrpsxsbg
- Pneumatic quill retraction
- Two-jaw bezel (range 8-75 mm)
