Flotation system / automatic coating machine

SARMAX APACHE 3

The APACHE 3 is a cost-effective solution suitable for both craft and industrial applications, specifically designed for coating facade claddings and their supporting substructures.

It is perfectly suited—without limitation—for coating profiles with cross-sections of 300 mm x 25 mm, providing flawless surfaces in a highly efficient and cost-saving manner, requiring no special prior knowledge from the operator.

This unit can also be integrated into automated systems or coating lines. It can coat boards, profiled boards, tongue-and-groove boards, rhomboid profiles, laminated timber, and structural timber, as well as decking, garden, log cabin, sauna or privacy screens. Essentially, it's ideal for any product requiring a premium-quality visible surface. Substructures (typically black) can also be coated with low-viscosity, highly pigmented stains containing wood preservatives—even without lateral brushes.

The APACHE 3 distinguishes itself from standard market products by its robust monoblock steel welded frame and a coating applied using a baking process with extremely resistant Teflon (enamel). This non-stick coating ensures self-cleaning, making the machine extremely low-maintenance.

The machine offered is brand new and available for demonstration in our showroom. We would be pleased to demonstrate our machines and systems either on-site or at customer locations in your vicinity.

For further information and a detailed description, please visit our SARMAX website.

APACHE 3
Serial number: SN 1171
Flood coating unit with three (3) brushes

Working width: 300 mm
Working height: 100 mm
Minimum workpiece length: 100 cm
Feed speed, frequency-controlled: 10–45 m/min
Number of driven transport rollers: 3
Diameter of transport rollers: 80 mm
Brush arrangement: two (2) from above, one (1) from below
Diameter of brushes: 160 mm
Central brush drive: 2.2 kW
Compressed air blow-off left/right, fan nozzles to clear tongue-and-groove: 80 l/min
Double diaphragm pump: 90 l/min
Compressed air consumption: 600 l/min
Connection: CEE plug 16 A 400/50/3 V/Hz/P E
Total power: 4.5 kW
Working height: 900 +/- 50 mm
Approximate weight: 450 kg
Iedpoxhquxjfx Ag Ueau
Operation: via control and indicator devices according to VDE, hydraulic ball valves
Dimensions (L/W/H): 1,900 x 1,300 x 1,500 mm
Standard: CE
Color, design: grey 7046 RAL
