Vertical broaching machine, broaching machine

Henning U6 /1000

Manufacturer: henning
Model: U6/1000
Hjdpfeup Uzfex Adiofb
Machine no.: 17065
Year of construction: 1979
Weight: 1.100 kg

General / technical data:
used mechanical vertical broaching machine Henning, in working condition
Tractive force: 6,000kg (60KN)
Clearing speeds: 3m/min and 6m/min
Return speed: 6m/min
maximum stroke: 1,000mm
maximum tool length: 1,200mm
table size / work surface: 600x460mm / 480 x340mm
Table aperture: Ø 170mm with eccentric table insert with Ø 90mm bore for standard broaching mandrels (Rausch system)
Workpiece diameter: any
Dimensions (h x w x d): 1,650mm x 1,200mm x 700mm (h= table height to floor without superstructure)
Motor: 7.4 /10kw
Power supply: 380 Volt / 50 HZ

Accessories / special equipment:

- Integrated coolant system
- Return circuit with double actuation mode
- Machine documentation
- Automatic clamping jaw opener in the lower drawbridge position (tool removal)
- Tool clamping with universal clamping jaws for flat shanks DIN 1416 BL 6

Remark:
The machine is in original condition, the function has been tested.
The machine is mechanically driven by a trapezoidal threaded spindle and a geared motor. In contrast to most mechanically driven broaching machines in which the trapezoidal spindle forms the drive and guide element, this machine has additional guide columns. The machine is therefore additionally column-guided and very stable.
The double spindle drive is ideal for a continuously constant cutting speed, even with higher tensile forces.
The machine is in our warehouse and can be inspected under power.
