CNC Bed-Type Milling Machine SACHMANN

Sachmann Rambaudi

CNC Bed-Type Milling Machine SACHMANN RAMBAUDI - MP-212 HS
MACH-ID 9328
Make: SACHMANN RAMBAUDI
Type: MP-212 HS
Control: HeidenHain iTNC530
Year: 2007
KOSMO 3 indexing head Sk-50, 0,02 Degrees, 1195 Nm
Spindle extention L = 600 mm with 2000 Rpm
3D Measuring probe MP60
ATC Chain 80 Positions
Coolant system 1320 L with 4,8 Bar
Rotary indexing table  2000 x 1600 x 15 ton
V-Axis (in feed) 1500 mm
Rotation 3 U/Min
HeidenHein RON 700 encoder for Table rotation
Ram size 500 x 500 with 56 kW
Chip conveyor


X-Axis: 6000mm
Y-Axis: 2000mm
Z-Axis: 1400mm
Table Length: 4000mm
Table Width: 2000mm
Table load: 25000
Power on spindle: 37kW
Spindle speeds: 2000Rpm
Spindle Taper: 50ISO/Bt/Mk
Feed rate X-Axis: 30000mm/min.
Cgsdpfxjx Nh H Ds Ah Hjn
Feed rate Y-Axis: 30000mm/min.
Feed rate Z-Axis: 30000mm/min.
Millinghead auto-index:2.5 x 2.5°
Length: 15000mm
Width: 8000mm
Height: 6000mm
Weight: 85000kg
Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
