Hydraulic press brake

DARLEY EHP 150 - 43/37

Hydraulic press brake
Gsdoh U A Ibspfx Ad Aoip
Fab. DARLEY Type. EHP 150 - 43/37
Very good condition, year 1992

Technical data

Make: DARLEY
Type: EHP 150 - 43/37
Year of manufacture: 1992
working length: 4300 mm
power: 150 t
distance machine column: 3700 mm
ram stroke: 175 mm
Engine power: 11 kW
Dimensions: approx. L 4.7 x W 1.6 x H 3.1 m (transport height 2.85 m)
Weight: approx. 16 t

Equipment:
- Control Delem DA 58
- Block die: V14, V60, V40, V24, V12, V30, V22, V10
- Punch straight height 195 mm, segmented
- 2. punch cranked height 195 mm, segmented, length 4.000mm
- controlled axes: Y1, Y2, X, R, Z
- motorized crowning
- 2 support arms
- operating instructions + test books

All data without guarantee.

The machine is in a very good condition. A demonstration under power is possible at any time in our exhibition hall.
