Press brake

Dener Abkantpresse XL30135

Comparable to Durma, Baykal, Ermaksan, etc.

Bending length: 3,020 mm
Pressing force: 135 t
Approach speed: 140 mm/s
Bending speed max.: 10 mm/s
Return speed: 130 mm/s
Stroke: 320 mm
Installation height: 550 mm
Throat depth: 450 mm
X-axis travel: 750 mm
X-axis speed: 300 mm/sec
R-axis travel: 250 mm
R-axis speed: 100 mm/sec
Clear distance between frames: 2,555 mm
Machine length: 3,730 mm
Machine width: 2,300 mm
Total height: 2,850 mm
Table height: 900 mm
Giodpsq Rdtqsfx Ab Tsr
Motor power: 15 kW
Oil tank: 190 l
Machine weight: 9,500 kg
(Technical data may vary depending on equipment)

Standard features:
- 3 CNC axes (Y1, Y2, X)
- Double-guided, stable, and precise ram
- Robust, double-guided backgauge
- Manually adjustable, double-guided stop fingers on linear guides
- Adjustable front support arms with height adjustment
- Lateral and rear safety covers
- Lower die adapter rail, 60 mm
- Manual upper tool clamping system (Promecam system)
- Manual crowning
- Foot switch with emergency stop
- 380 V, 50-60 Hz, 3-phase
- LED lighting

Recommended options:
- Dener DA 66T control
- Fiessler AKAS 2M laser finger protection
- FPSC Safety PLC (manual)
- X and R axes with servomotors
- CNC crowning for high bending accuracy
- 2 additional stop fingers

- Other working lengths and thicknesses available with suitable accessories! -
