Baler

Europress EP 6500 V5H4

Europress EP 6500 V5 H4, Cross Tying, Year 2009, Fully Workshop Overhauled

Technical Data:
Manufacturer: Europress
Type: 6500 V5 H4
Year of manufacture: 2009
Operating hours: approx. 15,334 hrs
Number of bales: 138,097
Main press force: 120 t
Specific press force: 142 kg/cm²
Feed opening dimensions: 1,650 x 1,100 mm
Fill volume: 3 m³
Filling volume per press cycle: 1.58 m³
Bale dimensions: 730 x 1,100 mm
Drive power: 75 kW (1 x 30 kW + 1 x 45 kW, individually switchable)
Total connected load: 83 kW
Current consumption: 150 A
Binding: 5-fold vertical, 4-fold horizontal, fully automatic
Bale weights: 450-900 kg
Hydraulic oil tank volume: 1,200 L
PLC control: Siemens S7-200
Operator panel: Siemens touchscreen
Press dimensions (assembled with hopper): 13,465 x 5,200 x 5,074 mm
Itodpfxjw Rlf Eo Abnjp
Transport dimensions (press only): 9,965 x 2,500 x 2,900 mm (L x W x H)
Machine weight (press): approx. 28 t

Overhaul Work Performed on the EP 6500 V5:
- Completely de-rusted and repainted
- Full renewal of the interior steel floor of the press
- Overhaul of plunger (steel construction)
- Complete overhaul of horizontal and vertical lance boxes
- Full replacement of internal Hardox lining
- All hydraulic hoses replaced
- Both lifting cylinders renewed
- Knives and counter-knives replaced
- All hydraulic cylinders resealed and tested
- All guide and sliding plastics renewed
- Wire deflection pulleys replaced
- Various cables and sensors replaced
- Various electrical components (control cabinet) renewed
- Complete check of electrical system/control
- Full pressure test of hydraulic system

Remarks:
The machine has been overhauled, checked, and tested by us. You can find a video on our website or YouTube channel.

Inspections, including powered operation, are possible at any time by appointment. On request, we are also happy to perform test runs with your material for a fee.

For questions about the machine, you may also contact us by phone from Monday to Thursday, 08:00 to 14:00. On Friday, we are available from 08:00 to 13:00.

Please note:
All technical data refer to the manufacturer’s specifications. No liability is accepted for the accuracy of the information provided or for any possible errors. This offer is non-binding, subject to prior sale and can be revoked at any time. Inspection possible by appointment. Sale is ex location, without warranty or guarantee.
