Balers

Maschinenfabrik Bermatingen GmbH &CO.KG, Dixi 80 SLD

Horizontal baler DIXI 80 SLD
2018-2021 Year of construction


Semi-automatic 80-tonne baling system for the economical volume reduction of residual materials (recyclables) in industry and trade:
Cardboard packaging
Tetra packaging
Films
PET bottles
Foam
Insulation boards
and other compressible materials.

Machine dimensions L x H x W approx. mm: 4,320 x 1830 x 2,154 mm
Gjdsqa Dq Djpfx An Tjiw
Filling opening W x H (standard) mm: 1,040 x 1,110 mm
Machine weight approx. kg: 8,000
Press force max. kN: 80 t / 800 kN
Ironing cycle (average value) approx. s: 35
Bale size W x H x L approx. mm: 1,120 x 1,120 x 1,200
Bale weight (depending on material) approx. kg: 550 - 650
Binding: manual
Number of bindings: 4, with wire with Quicklink wire
Drive power: 11 kW; 400V/32A
The presses are tested and functional and are offered with a fresh UVV and inspection in accordance with DGUV regulation 3.
The Dixi 60SLD is ready for immediate use.

On request, the Dixi 60 SLD can be completely overhauled for an additional charge.
This includes:
Replace all hydraulic hoses. Change the hydraulic oil and check the hydraulic unit. The hydraulic cylinders are checked and replaced if necessary.

Net price plus VAT and possible transportation.
The operating instructions are available and are supplied as a PDF file and in paper form.
