Universal machining center

Mikron HPM 450 U WPC

Mikron / GF HPM 450 U WPC with Pallet Changer

About the machine:
High-precision 5-axis simultaneous milling machine with 7-position pallet changer (WPC). Excellent condition, extensive equipment! Very low spindle hours!

Technical data:

- Heidenhain ITNC 530 HSCI
- X-axis: 600 mm
- Y-axis: 450 mm
- Z-axis: 450 mm
- B-axis: +45° / -120°
- C-axis: 360°
- Spindle speed range: 20,000 rpm
- Spindle drive: 23 / 30 kW
- Torque: 91 Nm
- Tool holder: HSK 63
- Pallet size: 280 x 280 mm
- Max. pallet load: 150 kg
- Number of tool magazine pockets: 60
- Max. tool diameter: 90 (130) mm
- Max. tool length: 200 mm
- Max. tool weight: 6 kg
- Tool change time: 3 sec.
- Feed force X-Y-Z: 5 kN
- Rapid feed X-Y-Z: 22 m/min
- Acceleration X-Y-Z: 5 m/s²
- Rapid traverse B-axis: 50 rpm
- Rapid traverse C-axis: 140 rpm

Accessories:
- 7 pallets, including 6 pallets with clamping devices (see photo)
- Electronic handwheel
- Infrared measuring probe
- Laser tool measurement
- Direct path measuring systems
- APS Advanced Process System
- ITC Intelligent Thermal Control
- rConnect Live Remote Control (1 year)
- KinematicsOpt
- CT 60 tool magazine
- DYNAFIX 7-position pallet changer
- SIGMATEC 15 / 900 cbm/h oil mist extraction system
- Tool blow-off device
- Blowing air at the spindle carriage
- Blowing air through the spindle center
- Internal coolant supply 18–70 bar
- Paper band filtration system
- Chip conveyor
- Spindle oil cooler

Machine dimensions L x W x H: 6600 x 4000 x 2800 mm

Weight: approx. 8,600 kg

An inspection/test under power onsite is of course possible.

We are not your average machine dealer – here, you will be advised by a CNC expert!

We are happy to offer you transport, installation and setup, as well as commissioning and a machine training session, all performed by our own technicians.
