NEW JAINNHER JHC-12S

With a capacity from 1 to 25mm with a standard workrest or 25 to 40mm with a special workrest, and a servo controlled regulating wheel, the JHC 12S is the most compact centreless grinder in the range.
A precision ground, the hydrostatic bearing assembly provides minimal friction and lateral displacement, along with extended wheel life under heavy grinding loads. The grinding wheel spindle runs on the hydrostatic bearings with an ultra-thin oil film between all touching surfaces. This provides a substantial reduction in wear and prolongs spindle trueness and longevity. The regulating wheel uses a Variable Speed Motor, controls the speed of the regulating wheel.

Iodpfx Aaenzhuxj Dstd
Specification
Europa Jainnher JHC 12S
Standard work rest diameter 1 - 25mm
Optional work rest diameter 25 - 40mm
Grinding wheel size : diameter x width x hole 305 x 150 x 120mm
Regulating wheel size : diameter x width x hole 205 x 150 x 90mm
Grinding wheel speed 1900 rpm
Regulating wheel speed 10 - 300 rpm (variable speed)
Grinding wheel motor 7.5 hp
Regulating wheel motor 2 HP
Hydraulic pump motor 1 HP
Coolant pump motor 1 / 8 hp
Regulating wheel feed on handwheel 4mm (rev)
0.02mm(Gra)
Table feed on handwheel 7mm (rev)
0.05mm(Gra)
Table micro feed on handwheel 0.2mm(rev)
0.001mm(Gra)
Dressing handwheel 1.25mm (rev)
0.01mm (Gra)
Regulating wheel tilt angle + 5 Deg -3 Deg
Regulating wheel swivel angle +/- 5 Deg
Floor space (approx) 1750 x 1350 x 1400 mm
Net weight (approx) 1600 kgs
Europa Jainnher JHC 12S Centreless Grinding Machine

Standard Equipment
Grinding wheel and grinding wheel flange
Regulating wheel and regulating wheel flange
Flange extractor
Diamond tool
Thrufeed standard workrest and blade
Infeed standard workrest and blade
Levelling screw and plate
Tool box and tools
Thrufeed process gauge
Thrufeed safety device
Work lamp
