Horizontal 5-axis pallet machining center - Flipping

TOPNC ähnlich BAVIUS Horizontal 5 Achs Paletten BAZ- Flipping

High-end 5-axis flipping machine for aluminum structural components available at short notice. 90–95% completed, available for on-site demonstration under power. Delivery approx. 3 months.

For sale is a state-of-the-art horizontal 5-axis flipping machine (HM2040AL-AC), specifically designed for machining large-format, thin-walled aluminum structural components in the aerospace sector.
The machine is approximately 90–95% completed, installed at the factory, and can be inspected under real machining conditions. 👉 This machine platform has already been installed more than 80 times.

Highlights
- Available at short notice (delivery time approx. 3 months)
- High-end configuration (Fischer / Siemens / Heidenhain)
- Full 5-axis machining in a single setup
- Integrated flipping system (90° rotation)
- Ideal for aerospace aluminum structures
- Very attractive price-performance ratio
- Includes 2 pallets sized 2000 x 4000 mm, setup station, and rotary table

Technical Data
- Travel: 4300 / 2200 / 650 mm
- Table size: 4000 × 2000 mm
- Max. load: 4000 kg
- Rapid traverse: 50 m/min
- Feed rate: 30 m/min
- Positioning accuracy: up to 0.008 mm
- Repeatability: up to 0.004 mm

Spindle
- Fischer (Switzerland)
- 30,000 rpm
- 125 kW
- 66 Nm
- HSK-A63
- ICS 70 bar

Features
- 5-axis torque motor swiveling head (zero-backlash)
- Siemens SINUMERIK 840D sl
- 60-position tool magazine
- Closed-loop measuring system (Heidenhain)
- Automatic flipping system
- High-pressure cooling
- Chip conveyor & central lubrication

Options
- Renishaw laser tool measurement
- Workpiece probe
- Ultrasonic thickness measurement (≤10 µm)
- Vacuum clamping system
- Spindle thermal compensation
Dsdsy H Ncbspfx Alyout
- R-TEST calibration system

Including setup station and pallets!
German service, spare parts warehouse, etc.
