Double face grinding machineDISKUS WERKE
DDS 750XR (KDE)
Double face grinding machine
DISKUS WERKE
DDS 750XR (KDE)
Година на производство
2012
Состојба
Користено
Локација
Düsseldorf

Сликите прикажуваат
Прикажи карта
Податоци за машината
- Ознака на машината:
- Double face grinding machine
- Произведувач:
- DISKUS WERKE
- Модел:
- DDS 750XR (KDE)
- Година на производство:
- 2012
- Состојба:
- многу добро (користено)
Цена и локација
- Локација:
- Akademiestraße 3, 40213 Düsseldorf, Deutschland

Повикајте
Детали за понудата
- ID на огласот:
- A19478946
- Ажурирање:
- последно на 10.11.2025
Опис
DISKUS DDS 750 XR – Technical Specifications
Machine type: vertical double-disc grinding machine
Model: DDS 750 XR
Grinding wheel diameter: 750 mm
Maximum grinding width (through-feed): 180 mm
Giedpfxswwrqcj Abxol
Maximum material thickness (through-feed): 30 mm
Maximum grinding width (plunge-cut): 300 mm
Maximum material thickness (plunge-cut): 80 mm
Grinding spindle 1 power: 48 kW
Grinding spindle 2 power: 48 kW
Grinding wheel surface speed (max): 63 m/s
Coolant delivery: through the spindle center
Feeder type: rotary feeder
Feeder speed range: 20 mm/min to 240 mm/min
Control system: Siemens 840 D CNC
Total machine height: approx. 3,100 mm
Overall weight: approx. 13,000 kg
Footprint requirements: length approx. 4,900 mm, width approx. 5,000 mm
Construction features: triangular rigid frame, linear-guide spindles, 16 CNC axes, central lubrication, coolant filtration
Machine type: vertical double-disc grinding machine
Model: DDS 750 XR
Grinding wheel diameter: 750 mm
Maximum grinding width (through-feed): 180 mm
Giedpfxswwrqcj Abxol
Maximum material thickness (through-feed): 30 mm
Maximum grinding width (plunge-cut): 300 mm
Maximum material thickness (plunge-cut): 80 mm
Grinding spindle 1 power: 48 kW
Grinding spindle 2 power: 48 kW
Grinding wheel surface speed (max): 63 m/s
Coolant delivery: through the spindle center
Feeder type: rotary feeder
Feeder speed range: 20 mm/min to 240 mm/min
Control system: Siemens 840 D CNC
Total machine height: approx. 3,100 mm
Overall weight: approx. 13,000 kg
Footprint requirements: length approx. 4,900 mm, width approx. 5,000 mm
Construction features: triangular rigid frame, linear-guide spindles, 16 CNC axes, central lubrication, coolant filtration
