Band Saw

MEP - Halbautomat SHARK 282 SXI EVO / MDE

cutting diameter 250 mm
capacity 90 degrees: flat 280 x 220 mm
capacity 90 degrees: square 220 x 220 mm
capacity 45 degrees: flat 220 x 200 mm
capacity 45 degrees: round 230 mm
capacity 45 degrees: square 200 x 200 mm
capacity 60 degrees: flat 140 x 100 mm
capacity 60 degrees: square 100 x 100 mm
capacity 60 degrees: round 150 mm
vice 285 mm
turning speed range: 36/72 m/min
dimensions of saw-band 2950 x 27 x 0,9 mm
total power requirement 1,5 / 1,8 kW
weight of the machine ca. 460 kg
dimensions of the machine ca. 1150 x 1970 mm
Equipment:
- robust electro-hydraulic semi-automatic band saw (INDUSTRY)
- with miter cuts from 45° right to 60° left
* Miter adjustment via large turntable
- MEP microprocessor control EVO to control all functions
* front right, rotatable
- optional manual or automatic lowering of the saw bow
* stepless adjustment of the saw bow lowering
- saw band guide made of hard metal plates
- hydraulic saw band tension - including digital value display
- 2x saw band speeds
- 1x BI-metal saw band
- 1x angle stop
- chip removal brush
- machine base frame with forklift pockets
- operating instructions in German

Functioning of semi-automatic operation:
- electro-hydraulic clamping of the vice
- electro-hydraulic lowering of the saw bow
Hjdpfx Adoxaa S Rj Dsff
- electro-hydraulic raising of the saw bow
- electro-hydraulic opening of the vice

SPECIAL ACCESSORIES INCLUDED:
- MEP LubeCut micro dosing device
