CNC Turning- and Milling Center

MORI SEIKI NL 2500 SMC / 700

turning diameter max. 356 mm
turning length 705 mm
control MSX 850 III MAPPS Mitsubishi
greates pass round over bed 923,8 mm
Swing dia. over traverse guideway 755 mm
standard turning dia. 275 mm
max. spindle speed 4.000 min/-1
power capacity - main spindel 18,5 / 15 kW
spindle nose JIS A2-8
spindle bearing diameter 140 mm
spindle bore 91 mm
max. bar capacity 80 mm
Iedpfxezb N Uxe Ag Ujau
chucking diameter 305 mm
C-Axis 0,001 °
Spindle speed range subspindle max. 6.000 min/-1
power capacity - Sub spindle 11 / 7,5 kW
spindle nose JIS A2-5
spindle bearing diameter 85 mm
spindle bore 43 mm
chucking diameter 210 mm
C-Axis 0,001 °
number of toolpositions 12 pos.
Number of driven toolspositions 12 pos.
Shank diameter 26 mm
Drill shank diameter 50 mm
Spindle speed - driven tool stations max. 6.000 min -1
turret change time 0,25 sec.
x-axis 260 mm
z-axis 795 mm
b-axis 734 mm
feed speeds max. 30.000 mm/min
rapid traverse X/Z/B: 30 m/min
rapid traverse C: 400 min/-1
total power requirement 39 kVA
weight of the machine ca. 6,0 t
dimensions of the machine ca. 5,0 x 2,5 x 2,3 m
CNC - Turning- and MillingCenter
MORI SEIKI - NL 2500 SMC / 700

- Tool-Drive
- C-Axis
- Subspindle

- WITHOUT extraction system
