Hydraulic press 160 ton

WMW Zeulenroda PYE 160 SS

Manufacturer: WMW Zeulenroda
Type: PYE 160 SS
Year of manufacture: 1980

C-frame construction
Die height 850 mm
Thickness bolster plate 100 mm
Throat C side 360 mm

Specifications
Godpfxjwp Nv Hs Ad Dsua
Metric US Standard
Capacity
160,000
Table length
1,250 mm
Table width
600 mm
Ram stroke
500 mm
Starting speed
100 mm/min
Working speed
10 mm/min
Return speed
125 mm/min
Power
22.5 kW

Dimensions (Estimate)
Length: 2,150 mm
Width: 1,250 mm
Height: 3,600 mm
Weight: 7,500 kg
