Hydraulic Press

WUXI HPHS-100T

HPFS series are suitable for processing metal materials, such as stamping, bending, compressing and drawing metal sheet etc. It can also be used for straightening, pressing, plastic molding, balsa wood punching and sintered parts compacting.
Nominal force 1000KN
Max. working pressure of liquid 25Mpa
Slider stroke 400mm
Max. opening height 700mm
Worktable size 1700 x 800mm
Idle speed of slider 100mm/s
Working speed od slider10-25mm/s
Return speed of slider 30-80mm/s
Csdpfx Aaequqc Ie Torh
Height above floor 800mm
Specification Unit Parameter
Model No. HPHS-100T
Nominal Pressure KN 1000
Return force KN 320
Slide Stroke mm 400
Max. Opening Height mm 700
Slider Speed:
-Downstream speed mm/s 100
-Pressing mm/s 10-25
-Return mm/s 30-80
Table Size:
-L.R. mm 1700
-F.B. mm 800
Overall dimensions:
-L.R. mm 2300
-F.B. mm 800
-Height above floor mm 3000
Servo motor Power KW 18.5
Voltage 400V, 50Hz, 3 Phase
Total Weight app. T 12
Below attached drawing with tech. specification
